A 45 degree elbow is the elbow which can change the flow direction in a 45 degree . As a joint, it is used between the two pipes which has this right angle.
45-Degree-Elbow
In the field of butt welding steel elbows, it looks like a half of the 90 degree elbow.Commonly,the 90 degree elbows can be a seamless elbow or a welded elbow. Bending the two ends of pipe to a angle of 45 degree, it is a 45 degree seamless elbow.
The 45 degree elbows usually are manufactured as LR (Long Radius) elbows.Only in little occasion, for example, very tight place, people use the short radius elbow.Because there is nearly no factory produce such 45 degree short radius elbow, engineers or workers would cut a 90 degree elbow into two 45 degree elbow instead.
45-degree-elbow-drawing
Standard: ASME/ANSI B16.28,B16.9, MSS-SP-75, DIN 2605, EN 10253-2 , JIS B2311,GOST 17375,ISO3419
Material: ASTM A234,ASTM A860, ASTM 403,DIN 17175, EN10228 …Carbon steel, stainless steel , alloy steel.
Size: 1/2″-96″. DN15-DN2400
Connect method: Butt welding.
Type:
Seamless: DN15-DN900,
Welded: DN100-DN1800
